On the surface this looks peaceful doesn't it? Beneath the engine hatch are 2 1100 hp MAN high performance diesel 10 Searayengines coupled to ZF transmissions. The boat is equipped with the Rexroth controls commonly seen on this power-train set up. Interestingly, the transmissions have trolling valves but the owner was unaware of these or how to operate them.

What this means to the average boat owner is that the same engines that give you so much pleasure as you clip along at 35 mph can create quite a bit of anxiety at the dock. All boat owners with this type of boat get familiar with the "half shift". You know what I mean, push it into gear and pull it out quickly before it leaps out of the slip.

By adding a Xenta Smart-Stick you can control all 2200 horsepower with your fingertips. Xenta requires using the trolling valves if the boats equipped with them.

Now for the technical stuff:

The 610 Searay has an Idle Speed of 625 rpm with 1.67 to 1 Transmissions. This equates to a minimum shaft speed of 375 rpm.  Given that the propellors are 30 x 39 1/2 and five bladed, the boat in its stock configuration lurches forward at almost 11 mph and will move forward 16 feet in seconds.

The Xenta Smart-Stick uses a signal to activate the trolling valves and when the transmissions engage they engage at 90% slip. As you push the joystick forward it is similar to letting the clutch out on your car. As the clutches engage we start forward motion with a shaft speed of 75 rpm. This brings your shaft speed down to approximately 1.25 rotations per minute. You don't even have to do the math to see how this allows for one handed confident control.

On this installation tied to the dock you can take the slack out of the docklines with the joystick. try to do that with the "Half Shift"

Our most recent installation is on a 2008 Mainship 43. The client chose to install the joystick          Xenta Smart Stick 43 Mainship                                         yacht control to allow him to remain confident in his ability to control the boat in close quarters.

As the pictures show the installation is seamless and the Xenta Smart-Stick look like it was installed at the factory.
The Mainship utilizes the Glendinning EEC3 throttle controls. This is perfect for the Xenta Smart-Stick. Glendinning has provided a Xenta interface and this installation is truly plug and play. The Xenta will use all the advantages provided by the EEC3 allowing the owner, a spry 74 year old to precisely control his boat with one hand.

Xenta Also works with Volvo EVC systems and Bosch Rexroth Controls.

I thought it would be helpful to put together a little animation that explained how the Xenta Smart-Stick works with your boat and gives you the stress free confident control that usually only comes with years of experience and a few close calls.



Recently observed a large express cruiser attempting to pull into the fuel dock. The wind was blowing hard off the dock, the captain  was coming in against the wind. He pulled up parallel to the dock and stopped hoping his wife  could perform a miracle. Tossing and securing an amidships line to the low floating dock cleat from the high side deck. You guessed it, before she could do anything, the boat was blown away from the dock.Xenta At Fuel dock

The Captain put his outside motor in forward to bring in the bow, then neutral. Next he pulled the outside motor in reverse to bring in the stern, a maneuver that helped the wind blow him further from the dock. Keep in mind on this day there was little room between the two other boats to fit your cruiser.

As most boaters know, when you screw up, there are "experts" everywhere telling you what you should have done.

Docking should be easy and not feared. Obviously, there are different ways to approach and tie to this fuel dock—some are easy, but most are difficult and may require several attempts.

With the Xenta Smart-Stick  and you and your crew won't fear docking, you'll dock with confidence and be the envy of your boating friends—even the "expert" coaches on the picnic table.
